Hazet 4812-23AF HD swivelling Probe 180 39 mm Front Camera

Physical CharacteristicsColorBlackLength2589 mmWidth35.4 mmHeight51.1 mmWeight0.61 kg1.34 lbDetailsMeasurement StandardMetricBatteriesinternal rechargeable batteryCable TypeProbe cableTemperature Range-10C to 60CFeaturesDiagnosis and documentation of cavities for damage assessment
Improved accuracy of detail thanks to HD camera
Smaller probe diameter 3.9 mm
Compatible with basic unit 4812-23G and 4812-11G
Including control unit to operate articulation, video recording, brightness control
Bending radius approx. 35 mm (-30% compared to conventional designs)
High mobility due to bilateral articulation
Full swivel up to 180 on both sides enables e.g. a real reverse view onto valves in the cylinder head
Front camera
Twofold dimmable LED light source
Light intensity: front LED 200300 Lux (measured at 5 cm distance)
Digital interface to basic unit: USB-C
Viewing angle (FOV): 90
Depth of focus (DOV): 10 100 mm
Resolution: HD 1280(H) x 720(V) pixels
Compression format: H.264
Operating temperature: -10C to 60C
Probe protection rating: IP67
Weight: 307 g
Improved accuracy of detail thanks to HD camera
Diagnosis of cavities for damage assessment
Image format: Jpeg
Video format: MOV
Protection rating probe: IP67 (when connected)
Probe cable: 1 m
Dimensions: 35.4 x 51.1 mm 2589 mm (W x H x L)General InformationBrandHazetCalifornia ResidentsProposition 65 WarningReturn PolicyNCNR - Non-Cancellable / Non-ReturnablePart Number4812-23AFProduct TypeHD swivelling probeUPC4000896249602
